Price : $105-115 / piece
Output Mode 1 : -1:NO(Normally open)
Working Mode : Triggered by photosensitive device (non-contact structure)
Trigger stroke : 2mm
Machine Type : Milling Machine, lathe machine
Application : machining centers and tool breakage monitoring
video outgoing-inspection : Provided
weight (kg) : 1.5
Working power supply : DC5-24V
Output Mode 2 : -2:NC(Normally closed)
Brand Name : Makinopc
warranty : 1 Year
Repeatability : 0.002mm (condition: operating speed 50-200mm/min)
Protection structure : IP68 (100 meters water/oil/corrosion resistant)
MOQ : 1 piece
Place of Origin : Guangdong, China
Electrical life : 6 million times
machinery test report : Not Available
Trigger gravity : 0.8N(Installation status must be vertical)
Product Name | Optical Tool Setting Instruments/Sensors | |
Product Model | m86d-20-1, m86d-20-2 | |
Output Mode | -1:NO(Normally open) | |
-2:NC(Normally closed) | ||
Working Mode | Triggered by photosensitive device (non-contact structure) | |
Working power supply | DC5-24V | |
Trigger stroke | 2mm | |
Repeatability | 0.002mm (condition: operating speed 50-200mm/min) | |
Electrical life | 6 million times | |
Protection structure | IP68 (100 meters water/oil/corrosion resistant) | |
Trigger gravity | 0.8N(Installation status must be vertical) | |
Counterblade material | Super hard tungsten steel | |
Counterblade Diameter | 20mm | |
Surface Finish | Grinding 4S | |
Load rating | DC24V/20mA(MAX) Recommended value 10mA resistive load | |
Cable Specification | Standard 5M oil-resistant 6-core wire (length can be customized) | |
Cable Sheath | 8mm/304 stainless steel protection tube/L1.5 meters | |
Work Indicator | The first signal indicator is green, the second signal indicator is red | |
Over-travel alarm signal | ||
Output Mode | NC Normally Closed (Emergency stop when signal is disconnected) | |
Load rating | DC24V/20mA(MAX) Recommended value 10mA resistive load | |







|
|
Makinopc IP68 Waterproof Oilproof Photoelectric Automatic Tool Setting Instrument Sensor DC5-24V 1 Year Warranty Machining Tool Images |
