IP67 Protection Class CNC Machinery Normally Open Magnetic Proximity Sensor Switch With M12 Screws ZPS023H

Name: IP67 Protection Class CNC Machinery Normally Open Magnetic Proximity Sensor Switch With M12 Screws ZPS023H
Brand: Makinopc
Price: 6.92 USD

Buy cheap IP67 Protection Class CNC Machinery Normally Open Magnetic Proximity Sensor Switch With M12 Screws ZPS023H product

Brand Name : Makinopc

Supply Voltage : DC5~24V

weight (kg) : 0.5

Shell material : Glass fiber reinforced resin: black

Detection Poles : ZPS023H-S: S pole; ZPS023H-N: N pole

Magnetic detection direction : Forward

Indicator light : Red color

MOQ : 1 piece

warranty : 1 Year

Magnetic sensitivity : ZPS023H-S:0.7±0.15mT; ZPS023H-N:0.8±0.15mT

Price : $6.92-7.95 / piece

Place of Origin : Guangdong, China

Current consumption : 15mA MAX

Output current : 12mA MAX

Response time : 5μ sec

Protection class : IP67

Machine Type : Punching Machine, Milling Machine, lathe machine, Grinding Machine, Drilling Machine

Contact Now

Products Description

Makinopc Factory Direct Supply DC5V 24V Magnetic Proximity Sensor Switch ZPS023H

Key Features

●Magnetic proximity sensors are sensors that operate ON and OFF according to changes in the strength of the magnetic field. ●The operating principle is the Hall principle, which detects the magnetic field according to its polarity, and the standard detection pole is the S pole. ●Because of the short response time (5μsec or less), it can also be used for tachometers and speedometers. ●Compared with general proximity sensors, it is characterized by high sensitivity, large detection distance, and small size. ●Can perform both home position and over-travel detection of servo mechanisms with only one dual sensor. ●Strong resistance to electromagnetic interference and high reliability.

Product Paramenters

Supply Voltage	DC5～24V
Detection Poles	ZPS023H-S: S pole
Detection Poles		ZPS023H-N: N pole
Magnetic sensitivity	ZPS023H-S：0.7±0.15mT
Magnetic sensitivity		ZPS023H-N：0.8±0.15mT
Magnetic detection direction	Forward
Output mode	NPN normally open (ON when close)
Output current	12mA MAX
Current consumption	15mA MAX
Response time	5μ sec
Withstanding Voltage	AC1000V
Withstanding Voltage		(1 minute, between the whole charging part and the case)
Insulation resistance	DC250V
Insulation resistance		(20MΩ or more, between the whole charging part and the case)
Operating Ambient Temperature	-20℃～+85℃ (no condensation)
Humidity	20～95%RH
Wire Specification	φ2.8×1m
		S pole: Gray
		N-pole: Black
Shell material	Glass fiber reinforced resin: black
Installation	M12 nut Tightening torque 2N-m
Installation		It is recommended to prevent loosening by using an adhesive or the like.
Mounting aperture processing size	φ12 +0.5 / 0
Indicator light	Red color
Protection Class	IP67

※Output conversion and current increase can be realized by wire attachment.

Details Images

IP67 Protection Class CNC Machinery Normally Open Magnetic Proximity Sensor Switch With M12 Screws ZPS023H

※Output conversion and current increase can be realized by wire attachment.
