IP65 Industrial Automation 5v DC Proximity Sensor Upward Detection Magnetic Encoder with 3 Core Wires ZPS004

Name: IP65 Industrial Automation 5v DC Proximity Sensor Upward Detection Magnetic Encoder with 3 Core Wires ZPS004
Brand: Makinopc
Price: 7.30 USD

Buy cheap IP65 Industrial Automation 5v DC Proximity Sensor Upward Detection Magnetic Encoder with 3 Core Wires ZPS004 product

Place of Origin : Guangdong, China

Brand Name : Makinopc

Supply Voltage : DC5~24

MOQ : 1 piece

Output mode : NPN normally open (ON when close)

Detection Poles : S-pole

Protection class : IP65

Machine Type : Punching Machine, Milling Machine, lathe machine, Grinding Machine, Drilling Machine

Output current : 15mA MAX

Price : $7.30-9.90 / piece

weight (kg) : 0.5

warranty : 1 Year

Current consumption : 12mA MAX

Magnetic sensitivity : 2.5~3.5mT

Magnetic detection direction : Upward

Response time : 5μ sec

Shell material : Glass fiber reinforced resin: Black

Contact Now

Products Description

Magnetic proximity sensors are a proven and popular choice for many types of applications. They are often used to monitor the open or closed status of windows, doors, gates, trunks, containers, remote dropboxes, and more in security, monitoring, and anti-tampering type applications.

Key Features

●Magnetic proximity sensors are sensors that operate ON and OFF according to changes in the strength of the magnetic field. ●The operating principle is the Hall principle, which detects the magnetic field according to its polarity, and the standard detection pole is the S pole. ●Because of the short response time (5μsec or less), it can also be used for tachometers and speedometers. ●Compared with general proximity sensors, it is characterized by high sensitivity, large detection distance, and small size. ●Can perform both home position and over-travel detection of servo mechanisms with only one dual sensor. ●Strong resistance to electromagnetic interference and high reliability.

Product Paramenters

Supply Voltage	DC5～24V
Detection Poles	S-pole
Magnetic sensitivity	2.5～3.5mT
Magnetic detection direction	Upward
Output mode	NPN normally open (ON when close)
Output current	15mA MAX
Current consumption	12mA MAX
Response time	5μ sec
Withstanding Voltage	AC1000V
Withstanding Voltage		(1 minute, between the whole charging part and the case)
Insulation resistance	DC250V
Insulation resistance		(20MΩ or more, between the whole charging part and the case)
Operating Ambient Temperature	-20℃～+85℃ (no condensation)
Humidity	20～95%RH
Wire Specification	3 core wires, φ0.9×0.3m
Shell material	Glass fiber reinforced resin: green
	M2 screw, tightening torque 0.15N-m
Protection class	IP65

Details Images

IP65 Industrial Automation 5v DC Proximity Sensor Upward Detection Magnetic Encoder with 3 Core Wires ZPS004
