Response time : 16μ sec
warranty : 1 Year
Machine Type : Punching Machine, Milling Machine, lathe machine, Grinding Machine, Drilling Machine
Detection Poles : ZPS014-S: S pole; ZPS014-N: N pole
Protection class : IP65
Magnetic detection direction : Downward
Supply Voltage : DC5~24V
Magnetic sensitivity : 3~4mT
Price : $9.70-12.70 / piece
weight (kg) : 0.5
MOQ : 1 piece
Current consumption : 4mA MAX
Installation : M2 screw, tightening torque 0.15N-m
Indicator light : Red color
Place of Origin : Guangdong, China
Brand Name : Makinopc
Shell material : Glass fiber reinforced resin: black
Supply Voltage | DC5~24V |
Detection Poles | ZPS014-S: S pole |
ZPS014-N: N pole | |
Magnetic sensitivity | 3~4mT |
Magnetic detection direction | Downward |
Output mode | NPN normally open (ON when close) |
Output current | 15mA MAX |
Current consumption | 4mA MAX |
Response time | 16μ sec |
Withstanding Voltage | AC1000V |
(1 minute, between the whole charging part and the case) | |
Insulation resistance | DC250V |
(20MΩ or more, between the whole charging part and the case) | |
Operating Ambient Temperature | -20℃~+85℃ (no condensation) |
Humidity | 20~95%RH |
Wire Specification | φ2.8×1m |
S pole: Gray | |
N-pole: Black | |
Shell material | Glass fiber reinforced resin: black |
Installation | M2 screw, tightening torque 0.15N-m |
Indicator light | Red color |
Protection class | IP65 |







|
|
DC5-24V LED Indicator Magnetic Reed Switch Sensor IP65 Protection Rating NPN Type Sensor for Industrial Automation Equipment Images |
